- Model: IVEM6048-II
- Rated Power: 6kVA / 6kW
- Output Voltage: 230Vac, single-phase
- Output Frequency: 50Hz / 60Hz (auto-sensing)
- Waveform: Pure sine wave
- Nominal Battery Voltage: 48VDC
- Surge Capacity: Up to 12kW (2× rated power)
MPPT Solar Charge Controller
- Max PV Input Power: 7.5kWp
- Max PV Open Circuit Voltage (Voc): 500VDC
- MPPT Voltage Range: 90–450VDC
- Max PV Charging Current: 120A
- Number of MPPTs: 1
- MPPT Efficiency: ≥ 98%
Battery Charging
- Charging Method: 3-stage (Bulk, Absorption, Float)
- Max Charging Current: 120A
- Charger Type: Integrated AC and PV battery charger
- Compatible Battery Types: Lithium, GEL, AGM, Lead-acid
Parallel & Communication
- Parallel Operation: Supports up to 12 units in parallel
- Communication Ports: RS485, USB, CAN, Dry Contact
- Monitoring: Built-in WiFi for remote monitoring
- Smart Generator Port: Configurable output duration
Mechanical
- Cooling: Forced air cooling
- Display: LCD + LED indicators
- Dimensions (L×W×H): Approx. 420 × 335 × 142 mm
- Weight: Approx. 12.5 kg
- Protection Index: IP21 (indoor use)
Environmental
- Operating Temperature: –10°C to +50°C
- Altitude: Up to 6,000 metres
- Relative Humidity: 5%–95% (non-condensing)
