Description
IET 550-Watt Monocrystalline Solar Panel IE-7M144-HC
The IET IE-7M144-HC is a 550-watt monocrystalline solar panel built for homes, businesses, farms, schools, clinics, institutions, NGOs, and commercial solar installations that need dependable power generation from a high-output module.
This panel uses monocrystalline PERC cell technology, a half-cell design, and multi-busbar technology to improve module performance, current collection, and reliability. It is designed to perform well under high-temperature and low-light conditions, making it suitable for practical solar installations in demanding environments.
With 550W rated output, 21.28% module efficiency, Voc of 50.0V, Vmp of 41.8V, Imp of 13.16A, Isc of 13.94A, 1000VDC / 1500VDC maximum system voltage, 25A maximum series fuse rating, and a 30-year linear power output warranty, this IET solar panel is a strong choice for customers who need reliable solar power with long-term warranty support.
3 Things to Consider When Buying a Solar Panel
- System design and compatibility: This 550W panel has a Voc of 50.0V and Isc of 13.94A at STC, so the installer must confirm string sizing against the inverter or MPPT charge controller voltage and current limits.
- Installation environment: The module is designed for good performance under high-temperature and low-light conditions, but final energy output still depends on roof direction, tilt angle, shading, ventilation, mounting quality, and site conditions.
- Handling and mounting: This is a large panel measuring 2279 x 1134 x 30mm and weighing 28kg, so proper transport, lifting, mounting rails, clamps, and installer handling are important.
Technical Specifications
- Brand: IET
- Series: IE-7M144-HC
- Model: IE-7M144-HC 550W
- Product Type: Monocrystalline Solar Panel
- Rated Power: 550W
- Cell Type: Monocrystalline PERC
- Cell Size: 182 x 91mm
- Number of Cells: 144 cells, 6 x 24 layout
- Module Construction: Half-cell monocrystalline module
- Maximum Power at STC: 550W
- Open-Circuit Voltage Voc: 50.0V
- Short-Circuit Current Isc: 13.94A
- Maximum Power Voltage Vmp: 41.8V
- Maximum Power Current Imp: 13.16A
- Module Efficiency at STC: 21.28%
- Maximum Power at NOCT: 411W
- Voc at NOCT: 46.1V
- Isc at NOCT: 11.28A
- Vmp at NOCT: 38.1V
- Imp at NOCT: 10.79A
- Power Tolerance: ±3%
- Maximum System Voltage: 1000VDC / 1500VDC
- Maximum Series Fuse Rating: 25A
- Operating Temperature: -40°C to +85°C
- Nominal Operating Cell Temperature: 43°C ±2°C
- Temperature Coefficient of Pmax: -0.35%/°C
- Temperature Coefficient of Voc: -0.28%/°C
- Temperature Coefficient of Isc: 0.046%/°C
- Front Cover: 3.2mm tempered glass with anti-reflective coating
- Frame: Anodised aluminium alloy
- Junction Box: IP68 rated, 3 diodes
- Cable: 4mm²
- Cable Length: Portrait 300mm, landscape 1300mm
- Connector: MC4 compatible
- Dimensions: 2279 x 1134 x 30mm
- Weight: 28kg
- Packaging: 36 pieces per pallet, 180 pieces per 20ft container, 720 pieces per 40ft HQ container
- Certifications: IEC 61215, IEC 61730, IEC 61701, IEC TS 62804, CE, MCS
- Management System Certifications: ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
What’s in the Box
- IET IE-7M144-HC 550W solar panel
- Factory-fitted output cables and MC4-compatible connectors
- Manufacturer documentation as supplied by vendor
Warranty
- 20-year product warranty
- 30-year linear power output warranty
Best For
This IET 550W solar panel is best for homes, businesses, farms, schools, clinics, NGOs, institutions, commercial buildings, and solar projects that need high-output monocrystalline panels with strong efficiency, durable construction, and long-term warranty support.
