MPPT Charge controllers
Showing all 16 resultsSorted by price: high to low
-
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT RS 450/200 Tr Isolated; 450V/200A 48V Charge Controller with Bluetooth
-6%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT RS 450/200 Tr Isolated; 450V/200A 48V Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT RS 450 200 Tr Isolated
- Rated charge current: 200 amps
- Maximum PV Open Circuit Voltage: 450 volts
- Battery voltage: 48V
- Ultra-fast Maximum Power Point Tracking (MPPT) Solar Charge Controller
The MPPT RS SmartSolar is a 48V solar charge controller with up to 450 VDC PV input and 200 A output. It is used in on-grid and off-grid solar applications where maximum battery charging power is required. - Multiple independent MPPT tracking inputs: With multiple MPPT trackers, you can optimise your solar panel design for maximum performance for your specific location.
- Isolated PV connections for additional safety: Full galvanic isolation between PV and battery connections provides additional overall system safety.
- Wide MPPT voltage range: 65–450 VDC PV operating range, with a 120 VDC PV startup voltage.
- Lightweight, efficient and quiet: Thanks to high-frequency technology and a new design this powerful charger weighs only 13.7 kg for the 200 A model. In addition to this, it has excellent efficiency, low standby power, and a very quiet operation.
- Display and Bluetooth: The display reads battery and controller parameters. The parameters can be accessed with a smartphone or other Bluetooth-enabled device. In addition, Bluetooth can be used to set up the system and to change settings with VictronConnect.
- PV isolation resistance monitoring for peace of mind at higher voltages: The MPPT RS continuously monitors the PV array and can detect if there are faults that reduce the isolation of the panels to unsafe levels.
- VE.Can and VE.Direct port: for connection to a GX device for system monitoring, data logging, and remote firmware updates. VE.Can allows for up to 25 units to be connected together in parallel and synchronise their charging.
- I/O Connections: programmable relay, temperature sensor, auxiliary, digital input and voltage sensor connections. The remote input can accept the Victron small BMS and other BMS with an allow-to-charge signal.
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT RS 450/100 – Tr Isolated; 450V/100A 48V Charge Controller with Bluetooth
-7%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT RS 450/100 – Tr Isolated; 450V/100A 48V Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT RS 450 100 – Tr
- Rated charge current: 100 amps
- Maximum PV Open Circuit Voltage: 450 volts
- Ultra-fast Maximum Power Point Tracking (MPPT) Solar Charge Controller
The MPPT RS SmartSolar is a 48V solar charge controller with up to 450 VDC PV input and 100 A output. It is used in on-grid and off-grid solar applications where maximum battery charging power is required. - Multiple independent MPPT tracking inputs: With multiple MPPT trackers, you can optimise your solar panel design for maximum performance for your specific location.
- Isolated PV connections for additional safety: Full galvanic isolation between PV and battery connections provides additional overall system safety.
- Wide MPPT voltage range: 65–450 VDC PV operating range, with a 120 VDC PV startup voltage.
- Lightweight, efficient and quiet: Thanks to high-frequency technology and a new design this powerful charger weighs only 7.9 kg for the 100 A model. In addition to this, it has excellent efficiency, low standby power, and a very quiet operation.
- Display and Bluetooth: The display reads battery and controller parameters. The parameters can be accessed with a smartphone or other Bluetooth-enabled device. In addition, Bluetooth can be used to set up the system and to change settings with VictronConnect.
- PV isolation resistance monitoring for peace of mind at higher voltages: The MPPT RS continuously monitors the PV array and can detect if there are faults that reduce the isolation of the panels to unsafe levels.
- VE.Can and VE.Direct port: for connection to a GX device for system monitoring, data logging, and remote firmware updates. VE.Can allows for up to 25 units to be connected together in parallel and synchronise their charging.
- I/O Connections: programmable relay, temperature sensor, auxiliary, digital input and voltage sensor connections. The remote input can accept the Victron smallBMS, and other BMS with an allow-to-charge signal.
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT 250/100Tr VE.Can; 250V 100A 12/24/36/48 Charge Controller with Bluetooth
-33%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT 250/100Tr VE.Can; 250V 100A 12/24/36/48 Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT 250/100Tr VE.Can
- Rated charge current: 100A
- Maximum PV Open Circuit Voltage: 250V
- Ultra-fast Maximum Power Point Tracking (MPPT): Improves energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
- Advanced Maximum Power Point Detection in case of partial shading conditions: The innovative SmartSolar algorithm will always maximise energy harvest by locking to the optimum MPP.
- Outstanding conversion efficiency: No cooling fan. Maximum efficiency exceeds 99%.
- Flexible charge algorithm: Fully programmable charge algorithm, and eight pre-programmed algorithms, selectable with a rotary switch.
- Extensive electronic protection: over-temperature protection and power derating when the temperature is high, PV short circuit and PV reverse polarity protection, and PV reverse current protection.
- Bluetooth Smart built-in: The wireless solution to set up, monitor, update, and synchronise SmartSolar Charge Controllers.
- Internal temperature sensor and optional external battery voltage, temperature, and current sensing via Bluetooth: A Smart Battery Sense, a BMV-712 Smart Battery Monitor, or a SmartShunt can be used to communicate battery voltage and temperature (and current, in the case of a BMV-712 or a SmartShunt) to one or more SmartSolar Charge Controllers.
- VE.Direct or VE.Can: For a wired data connection to a Colour Control GX, other GX products, PC, or other devices.
- Synchronized parallel charging with VE.Can or Bluetooth: Up to 25 units can be synchronised with VE.Can, and up to 10 units with Bluetooth.
- Fully discharged battery recovery function will initiate charging even if the battery has been discharged to zero volts. will reconnect to a fully discharged Li-ion battery with an integrated disconnect function.
- Remote on-off: To connect, for example, to a VE.BUS BMS.
- Programmable relay: can be programmed to trip on an alarm or other events.
- Optional: SmartSolar pluggable LCD display.
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT 150/100Tr VE.Can; 150V 100A 12/24/36/48 Charge Controller with Bluetooth
-24%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT 150/100Tr VE.Can; 150V 100A 12/24/36/48 Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT 150/100Tr VE.Can
-
Ultra-fast MPPT: Enhances energy harvest by up to 30% compared to PWM controllers and up to 10% compared to slower MPPT controllers, especially in varying light conditions.
-
Advanced MPPT Detection: Optimises energy harvest under partial shading conditions by ensuring the controller locks onto the optimal MPP, avoiding suboptimal points.
-
High Efficiency: No cooling fan is required; efficiency exceeds 98%.
-
Flexible Charge Algorithm: Fully programmable with eight pre-set algorithms, offering customisation for different battery types.
-
Robust Protection: Includes over-temperature, PV short circuit, reverse polarity, and current protection.
-
Bluetooth Smart Built-in: Enables wireless setup, monitoring, updates, and synchronisation with other Victron devices.
-
Wired Connectivity: Options for VE.Direct or VE.Can connect to other systems or monitoring devices.
-
Battery Recovery Function: Capable of charging batteries discharged to zero volts and reconnecting to fully discharged Li-ion batteries with integrated disconnect functions.
-
Programmable Relay: Allows for custom alarms or event-triggered actions.
-
Optional LCD Display: Easily attachable to the front of the controller for on-site monitoring
SKU: n/a -
-
MPPT Charge controllers, Solar Charge Controllers, TBB Charge Controllers
TBB SolarMate 250V 100A MPPT Solar Charge Controller SP250/100; 48V, Bluetooth LCD Display, High Efficiency, 5880W/7500W, 250Vpv Input
-24%
MPPT Charge controllers, Solar Charge Controllers, TBB Charge ControllersTBB SolarMate 250V 100A MPPT Solar Charge Controller SP250/100; 48V, Bluetooth LCD Display, High Efficiency, 5880W/7500W, 250Vpv Input
TBB SolarMate 250V 100A MPPT Solar Charge Controller SP250/100
- Nominal Battery Voltage: 48V
- Maximum Charging Current: 100A
- Maximum Charging Power:
- 48V: 5,880W
- Maximum PV Input Power:
- 48V: 7,500W
- Maximum PV Input Voltage (Voc): 250V
- MPPT Voltage Range: 65–245V
- Max PV Short Circuit Current: 80A
- Efficiency:
- Maximum MPPT Efficiency: ≥99.9%
- Overall Efficiency: Up to 98%
- Self-Consumption: 37mA @ 48V
Charging Parameters:
- Charge Voltage (Absorption): 57.6V
- Charge Voltage (Float): 54V
- Charging Algorithm: TBB Premium II multistage
- Temperature Compensation: -3mV/°C/cell (default)
- Equalization Charging: Programmable
- Display: LED + LCD
- Communication Port: RS485, with support for auxiliary contact and T-Bus communication
- Parallel Functionality: Up to 6 units can operate in parallel for scalability
- Data Logging: 365 days of historical records, including:
- Real-time solar array voltage, battery voltage, and charging data
- Logs for PV start charging time, transfer to float, power loss, and fault time
- Cooling: Forced fan
- Operating Temperature: -25°C to 60°C (power derated above 40°C)
- Storage Temperature: -40°C to 70°C
- Humidity: 5%–95% (non-condensing)
- Altitude: Up to 3,000m (fully rated up to 2,000m)
Physical:
- Protection Category: IP21
- Dimensions (L × W × H): 352.2 × 293 × 116.2 mm
- Weight: 7.8 kg
Certifications:
- EN61000-6-1, EN61000-6-3, EN62109-1
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT 150/70Tr VE.Can; 150V 70A 12/24/36/48 Charge Controller with Bluetooth
-26%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT 150/70Tr VE.Can; 150V 70A 12/24/36/48 Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT 150/70Tr VE.Can
- Rated charge current: 70A
- Maximum PV Open Circuit Voltage: 150V
- Ultra-fast MPPT: Enhances energy harvest by up to 30% compared to PWM controllers and up to 10% compared to slower MPPT controllers, especially in varying light conditions.
- Advanced MPPT Detection: Optimises energy harvest under partial shading conditions by ensuring the controller locks onto the optimal MPP, avoiding suboptimal points.
- High Efficiency: No cooling fan is required; efficiency exceeds 98%.
- Flexible Charge Algorithm: Fully programmable with eight pre-set algorithms, offering customisation for different battery types.
- Robust Protection: Includes over-temperature, PV short circuit, reverse polarity, and current protection.
- Bluetooth Smart Built-in: Enables wireless setup, monitoring, updates, and synchronisation with other Victron devices.
- Wired Connectivity: Options for VE.Direct or VE.Can connect to other systems or monitoring devices.
- Battery Recovery Function: Capable of charging batteries discharged to zero volts and reconnecting to fully discharged Li-ion batteries with integrated disconnect functions.
- Programmable Relay: Allows for custom alarms or event-triggered actions.
- Optional LCD Display: Easily attachable to the front of the controller for on-site monitoring
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, TBB Charge Controllers
TBB SolarMate 150V 80A MPPT Solar Charge Controller SP150-80; 24V/48V, Bluetooth LCD Display, High Efficiency, 3000W/6000W, 150Vpv Input
-24%MPPT Charge controllers, Solar Charge Controllers, TBB Charge ControllersTBB SolarMate 150V 80A MPPT Solar Charge Controller SP150-80; 24V/48V, Bluetooth LCD Display, High Efficiency, 3000W/6000W, 150Vpv Input
TBB SolarMate 150V 80A MPPT Solar Charge Controller SP150-80
- Nominal Battery Voltage: Compatible with 24V and 48V systems.
- Maximum Charging Current: 80 Amperes.
- Maximum PV Input Power:
- 24V system: up to 4,500W
- 48V system: up to 9,000W
- Maximum PV Input Voltage: 150V.
- MPPT Voltage Range: 65V to 145V.
- Maximum Efficiency: Up to 98%.
- MPPT Efficiency: Up to 99.9%.
Charging Parameters:
- Absorption Charge Voltage:
- 24V system: 28.8V
- 48V system: 57.6V
- Float Charge Voltage:
- 24V system: 27.0V
- 48V system: 54.0V
- Charging Algorithm: TBB Premium III multistage charging, suitable for various lead-acid and lithium-ion battery types.
Physical Specifications:
- Dimensions: 353 mm (H) x 293 mm (W) x 117 mm (D).
- Weight: 7.8 kg.
- Protection Class: IP21.
- Operating Temperature Range: -25°C to +60°C.
- Humidity: 5% to 95% (non-condensing).
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 120A 48V MPPT Solar Charge Controller SCCM12048-II; 195V/120A, up to 6600Wpv @ 48V, 3300Wpv @24V, 1650Wpv @12V
-22%
MPPT Charge controllers, Solar Charge ControllersFelicity 120A 48V MPPT Solar Charge Controller SCCM12048-II; 195V/120A, up to 6600Wpv @ 48V, 3300Wpv @24V, 1650Wpv @12V
Felicity 120A 48V MPPT Solar Charge Controller SCCM12048-II
- System voltage: 12V/24V/48/(Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V/48V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 120A
- Max PV Input Power @12V = 1650W,
- Max PV Input Power @24V = 3300W,
- Max PV Input Power @48V = 6,600W
- PV Array MPPT Vol Range: 15V-170V/ 30-170V/ 60-170V
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight:
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 100A 48V MPPT Solar Charge Controller SCCM10048; 195V/100A, up to 5,500Wpv @ 48V, 2750Wpv @24V, 1375Wpv @12V
-20%
MPPT Charge controllers, Solar Charge ControllersFelicity 100A 48V MPPT Solar Charge Controller SCCM10048; 195V/100A, up to 5,500Wpv @ 48V, 2750Wpv @24V, 1375Wpv @12V
Felicity 100A 48V MPPT Solar Charge Controller SCCM10048
- System voltage: 12V/24V/48/(Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V/48V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 100A
- Max PV Input Power @12V = 1375W,
- Max PV Input Power @24V = 2750W,
- Max PV Input Power @48V = 5500W
- PV Array MPPT Vol Range: 15V-170V/ 30-170V/ 60-170V
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 7kg
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 80A 48V MPPT Solar Charge Controller SCCM8048-II; 145V/80A, up to 4400Wpv @ 48V, 2200Wpv @24V, 1100Wpv @12V
-21%
MPPT Charge controllers, Solar Charge ControllersFelicity 80A 48V MPPT Solar Charge Controller SCCM8048-II; 145V/80A, up to 4400Wpv @ 48V, 2200Wpv @24V, 1100Wpv @12V
Felicity 80A 48V MPPT Solar Charge Controller SCCM8048-II
- Maximum Solar Input Voltage: 145V
- PV Start-up Voltage: 15V
- PV Array MPPT Voltage Range: 15-130V DC/30-130V DC/ 60-130V DC
- System voltage: 12V/24V/48/(Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V/48V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 80A
- Max PV Input Power @12V = 1,100W,
- Max PV Input Power @24V = 2,200W,
- Max PV Input Power @48V = 4,400W
- PV Array MPPT Vol Range: 15V-170V/ 30-170V/ 60-170V
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 5.9kg
- Protections:
Solar High Voltage Disconnect
Solar High Voltage Reconnect
Battery High Voltage Disconnect
Battery High Voltage Reconnect
High Temperature Disconnect
High-Temperature Reconnect
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 60A MPPT Solar Charge Controller SCCM6048-II; 145V/60A, up to 3300Wpv @ 48V, 1650Wpv @24V, 825Wpv @12V
-22%
MPPT Charge controllers, Solar Charge ControllersFelicity 60A MPPT Solar Charge Controller SCCM6048-II; 145V/60A, up to 3300Wpv @ 48V, 1650Wpv @24V, 825Wpv @12V
Felicity 60A MPPT Solar Charge Controller SCCM6048-II
-
Compatible for PV systems in 12V, 24V or 48V
-
Maximum charging current up to 60A
-
Automatic battery voltage detection (lithium battery voltage needs to be set manually)
-
Supports lithium battery and various lead-acid batteries, AGM and gel battery
-
Integrated intelligent slot compatible with MODBUS communication
-
Caution, risk of electric shock, energy storage timed discharge.
Specifications
- Maximum Solar Input Voltage: 145V
- PV Start-up Voltage: 15V
- System voltage: 12V/24V/48/(Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V/48V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 60A
- Max PV Input Power @12V = 825W,
- Max PV Input Power @24V = 1,650W,
- Max PV Input Power @48V = 3,300W
- PV Array MPPT Voltage Range: 15-130V DC/30-130V DC/ 60-130V DC
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 4.7kg
- Protections:
Solar High Voltage Disconnect
Solar High Voltage Reconnect
Battery High Voltage Disconnect
Battery High Voltage Reconnect
High Temperature Disconnect
High-Temperature Reconnect
SKU: n/a -
-
MPPT Charge controllers, Solar Charge Controllers, TBB Charge Controllers
TBB SolarMate 100V 40A MPPT Solar Charge Controller SP100-40; 12V/24V/48V, Bluetooth Display, High Efficiency, 588W/1176W/2352W, 100Vpv input
-16%
MPPT Charge controllers, Solar Charge Controllers, TBB Charge ControllersTBB SolarMate 100V 40A MPPT Solar Charge Controller SP100-40; 12V/24V/48V, Bluetooth Display, High Efficiency, 588W/1176W/2352W, 100Vpv input
TBB SolarMate 100V 40A MPPT Solar Charge Controller SP100-40
- Nominal Battery Voltage: Compatible with 12V, 24V, and 48V systems.
- Maximum Charging Current: 40 Amperes.
- Maximum PV Input Power:
- 12V system: up to 588W
- 24V system: up to 1176W
- 48V system: up to 2352W
- Maximum PV Input Voltage: 100V.
- Maximum Efficiency: Up to 98.2%.
- MPPT Efficiency: Up to 99%.
Charging Parameters:
- Absorption Charge Voltage:
- 12V system: 14.4V
- 24V system: 28.8V
- 48V system: 57.6V
- Float Charge Voltage:
- 12V system: 13.5V
- 24V system: 27.0V
- 48V system: 54.0V
- Charging Algorithm: TBB Premium II multistage charging, suitable for various lead-acid battery types.
Physical Specifications:
- Dimensions: 205 mm (H) x 160 mm (W) x 65 mm (D).
- Weight: 1.4 kg.
- Protection Class: IP31.
- Operating Temperature Range: -40°C to +70°C.
- Humidity: 5% to 95% (non-condensing)
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge Controllers
Victron SmartSolar Charge Controller MPPT 100/30; 100V 30A 12/24V Charge Controller with Bluetooth
-30%
MPPT Charge controllers, Solar Charge Controllers, Victron Solar Charge ControllersVictron SmartSolar Charge Controller MPPT 100/30; 100V 30A 12/24V Charge Controller with Bluetooth
Victron SmartSolar Charge Controller MPPT 100/30
- Rated Charge Current: 30 A,
- Maximum PV Open Circuit Voltage: 100 V
- Ultra-fast MPPT: Improves energy harvest by up to 30% compared to PWM controllers.
- Advanced MPPT Detection: Maximises energy harvest even in partial shading conditions.
- High Efficiency: Features an outstanding conversion efficiency of over 98% without the need for a cooling fan.
- Flexible Charge Algorithm: Fully programmable with multiple pre-set algorithms.
- Extensive Protection: Includes over-temperature, PV short circuit, PV reverse polarity, and reverse current protection.
- Bluetooth Smart Built-in: Allows for wireless setup, monitoring, updates, and synchronisation.
- VE.Direct Port: For wired connections to various devices.
- Battery Recovery Function: Can initiate charging for batteries discharged to zero volts and reconnect to fully discharged Li-ion batteries.
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 45A MPPT Solar Charge Controller SCCM4524-II; 95V/45A, up to 1250Wpv @24V, 625Wpv @12V
-14%
MPPT Charge controllers, Solar Charge ControllersFelicity 45A MPPT Solar Charge Controller SCCM4524-II; 95V/45A, up to 1250Wpv @24V, 625Wpv @12V
Felicity 45A MPPT Solar Charge Controller SCCM4524-II
- Compatible for PV systems in 12V, 24V
- Maximum charging current up to 45A
- Automatic battery voltage detection (lithium battery voltage needs to be set manually)
- Supports lithium battery and various lead-acid batteries, AGM and gel battery
- Integrated intelligent slot compatible with MODBUS communication
- Caution, risk of electric shock, energy storage timed discharge.
- Charging Stages: Bulk, Absorption, Float
- Temperature Compensation Coefficient: -5mV/℃/cell (25°C ref.)
- Temperature Compensation Range: 0°C to 50°C
- Transient Surge Protection: 4500 Watts/port
Specifications
- Maximum Solar Input Voltage: 95V
- PV Start-up Voltage: 15V
- System voltage: 12V/24V (Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 45A
- Max PV Input Power @12V = 625W,
- Max PV Input Power @24V = 1,250W,
- PV Array MPPT Voltage Range: 15-80V DC/30-80V DC
- PV array: 12V DC/24V DC
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 1.8kg
- Protections:
Solar High Voltage Disconnect
Solar High Voltage Reconnect
Battery High Voltage Disconnect
Battery High Voltage Reconnect
High Temperature Disconnect
High-Temperature Reconnect
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers
Felicity 30A MPPT Solar Charge Controller SCCM3024-II; 95V/30A, up to 830Wpv @24V, 420Wpv @12V
-0%
MPPT Charge controllers, Solar Charge ControllersFelicity 30A MPPT Solar Charge Controller SCCM3024-II; 95V/30A, up to 830Wpv @24V, 420Wpv @12V
Felicity 30A MPPT Solar Charge Controller SCCM3024-II
- Compatible for PV systems in 12V, 24V
- Maximum charging current up to 30A
- Automatic battery voltage detection (lithium battery voltage needs to be set manually)
- Supports lithium battery and various lead-acid batteries, AGM and gel battery
- Integrated intelligent slot compatible with MODBUS communication
- Caution, risk of electric shock, energy storage timed discharge.
- Charging Stages: Bulk, Absorption, Float
- Temperature Compensation Coefficient: -5mV/℃/cell (25°C ref.)
- Temperature Compensation Range: 0°C to 50°C
- Transient Surge Protection: 4500 Watts/port
Specifications
- Maximum Solar Input Voltage: 95V
- PV Start-up Voltage: 15V
- System voltage: 12V/24V (Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 30A
- Max PV Input Power @12V = 420W,
- Max PV Input Power @24V = 830W,
- PV Array MPPT Voltage Range: 15-80V DC/30-80V DC
- PV array: 12V DC/24V DC
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 1.2kg
- Protections:
Solar High Voltage Disconnect
Solar High Voltage Reconnect
Battery High Voltage Disconnect
Battery High Voltage Reconnect
High Temperature Disconnect
High-Temperature Reconnect
SKU: n/a -
MPPT Charge controllers, Solar Charge Controllers, TBB Charge Controllers
TBB SolarMate 100V 20A MPPT Solar Charge Controller SP100-20; 12V/24V/48V, Bluetooth Display, High Efficiency, 294W/588W/1176W, 100Vpv input
-55%
MPPT Charge controllers, Solar Charge Controllers, TBB Charge ControllersTBB SolarMate 100V 20A MPPT Solar Charge Controller SP100-20; 12V/24V/48V, Bluetooth Display, High Efficiency, 294W/588W/1176W, 100Vpv input
TBB SolarMate 100V 20A MPPT Solar Charge Controller SP100-20
- Nominal Battery Voltage: Compatible with 12V, 24V, and 48V systems.
- Maximum Charging Current: 20 Amperes.
- Maximum PV Input Power:
- 12V system: up to 294W
- 24V system: up to 588W
- 48V system: up to 1176W
- Maximum PV Input Voltage: 100V.
- Maximum Efficiency: Up to 98.2%.
- MPPT Efficiency: Up to 99%.
Charging Parameters:
- Absorption Charge Voltage:
- 12V system: 14.4V
- 24V system: 28.8V
- 48V system: 57.6V
- Float Charge Voltage:
- 12V system: 13.5V
- 24V system: 27.0V
- 48V system: 54.0V
- Charging Algorithm: TBB Premium II multistage charging, suitable for various lead-acid battery types.
Physical Specifications:
- Dimensions: 205 mm (H) x 160 mm (W) x 65 mm (D).
- Weight: 1.4 kg.
- Protection Class: IP31.
- Operating Temperature Range: -40°C to +70°C.
- Humidity: 5% to 95% (non-condensing).
Features:
- Bluetooth connectivity: allows monitoring and configuration via the TBB SolarMate app.
- LCD Display: Provides real-time system status and data.
- Communication Port: RS485 interface for integration with other devices.
- Data Logging: Supports 365 days of historical data recording.
- Protection Features: Includes over-temperature, over-voltage, and over-current protections.
SKU: n/a
