Victron 250VA 12V Phoenix Inverter VE.Direct; Pure Sine Wave, 200W Continuous Power, 400W Peak, ECO Mode, Remote On/Off, Compact Design

• Pure Sine Wave Output: Ensures compatibility with sensitive electronics.
• VE.Direct Port: Enables full configuration and monitoring via PC, smartphone, or tablet (Bluetooth dongle or USB cable required).
• ECO Mode: Saves energy by switching off at low loads and restarting at adjustable intervals.
• High Start-up Power: Capable of starting demanding loads such as LED drivers and power tools.
• Remote On/Off: Can be remotely controlled via a switch or relay.
• LED Diagnostics: For quick fault detection and operational status.
• Proven Reliability: Full bridge topology with toroidal transformer for durable performance.

Victron 250VA 12V Phoenix Inverter VE.Direct specifications

• Continuous Output Power: 200W at 40°C (250VA at 25°C)
• Peak Power: 400W
• Output Voltage / Frequency: 230VAC ±3%, 50Hz or 60Hz (selectable)
• Input Voltage Range: 9.2V – 17.0V DC
• Efficiency: Up to 87%
• Zero-load Power Consumption: 4.2W (0.8W in ECO mode)
• Dimensions (H x W x D): 86 x 165 x 260 mm
• Weight: 2.4 kg
• DC Connection: Screw terminals (no special tools needed)
• AC Output Socket: Schuko or IEC-320 (check model variant)
• Protection: Short circuit, overload, over-voltage, under-voltage, over-temperature
• Cooling: Fan assisted, with derating above 40°C
• Ingress Protection: IP21
• Operating Temperature: -40°C to +65°C

Ideal For:

• Powering small AC devices off-grid
• Vehicle-based power systems (RVs, boats)
• Backup power for lights and electronics
• Remote installations requiring efficient small inverters
