Jinko Solar 475-Watt 24V Monocrystalline Solar Panel JKM475N-60H; Voc 42.54V, Vmp 35.21V, Imp 13.49A, Isc 14.23A, Module efficiency of 22.01%

Description

Jinko Solar 475-Watt 24V Monocrystalline Solar Panel JKM475N-60H

Key Specifications:

• Maximum Power (Pmax): 475 Wp
• Module Efficiency: 22.01%
• Maximum Power Voltage (Vmp): 35.21 V
• Maximum Power Current (Imp): 13.49 A
• Open-Circuit Voltage (Voc): 42.54 V
• Short-Circuit Current (Isc): 14.23 A

Mechanical Characteristics:

• Dimensions: 1903 mm x 1134 mm x 30 mm
• Weight: 24.2 kg
• Cell Type: N-type monocrystalline
• Number of Cells: 120 (6×20)
• Front Glass: 3.2 mm, anti-reflection coating, high transmission, low iron, tempered glass
• Frame: Anodized aluminium alloy
• Junction Box: IP68 rated
• Output Cables: TUV 1×4.0 mm², with lengths of (+): 400 mm and (-): 200 mm (customizable)

Performance Under Standard Test Conditions (STC):

• Operating Temperature Range: -40°C to +85°C
• Maximum System Voltage: 1000/1500 VDC (IEC)
• Maximum Series Fuse Rating: 25 A
• Power Tolerance: 0~+3%
• Temperature Coefficients:
  • Pmax: -0.29%/°C
  • Voc: -0.25%/°C
  • Isc: +0.045%/°C

Certifications and Warranties:

• Product Warranty: 12 years
• Linear Power Warranty: 30 years with a degradation rate of 0.40% annually, ensuring 87.4% of the initial power output after 30 years
• Certifications: IEC61215(2016), IEC61730(2016), ISO9001:2015 (Quality Management System), ISO14001:2015 (Environment Management System), ISO45001:2018 (Occupational Health and Safety Management Systems)

Additional Features:

• Enhanced Mechanical Load: Certified to withstand wind loads up to 2400 Pa and snow loads up to 5400 Pa
• PID Resistance: Excellent Anti-PID performance through optimized mass-production processes and material control
• Durability: High resistance to salt mist and ammonia, making it suitable for various environmental conditions
