FREE DELIVERYMPPT Charge controllers, Solar Charge Controllers
Felicity 30A MPPT Solar Charge Controller SCCM3024-II; 95V/30A, up to 830Wpv @24V, 420Wpv @12V
-0%
MPPT Charge controllers, Solar Charge ControllersFelicity 30A MPPT Solar Charge Controller SCCM3024-II; 95V/30A, up to 830Wpv @24V, 420Wpv @12V
Felicity 30A MPPT Solar Charge Controller SCCM3024-II
- Compatible for PV systems in 12V, 24V
- Maximum charging current up to 30A
- Automatic battery voltage detection (lithium battery voltage needs to be set manually)
- Supports lithium battery and various lead-acid batteries, AGM and gel battery
- Integrated intelligent slot compatible with MODBUS communication
- Caution, risk of electric shock, energy storage timed discharge.
- Charging Stages: Bulk, Absorption, Float
- Temperature Compensation Coefficient: -5mV/℃/cell (25°C ref.)
- Temperature Compensation Range: 0°C to 50°C
- Transient Surge Protection: 4500 Watts/port
Specifications
- Maximum Solar Input Voltage: 95V
- PV Start-up Voltage: 15V
- System voltage: 12V/24V (Auto detection)
- Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
- Automatic battery voltage detection (12V/24V)
- Three-stage charging optimises battery performance
- Charging Stages: bulk, absorption, floatBulk, absorption, float
- Maximum charging current up to 30A
- Max PV Input Power @12V = 420W,
- Max PV Input Power @24V = 830W,
- PV Array MPPT Voltage Range: 15-80V DC/30-80V DC
- PV array: 12V DC/24V DC
- Maximum efficiency up to 98%• Battery temperature sensor (BTS) automatically provides temperature compensation
- Integrated intelligent slot compatible with SNMP/MODBUS communication
- Weight: 1.2kg
- Protections:
Solar High Voltage Disconnect
Solar High Voltage Reconnect
Battery High Voltage Disconnect
Battery High Voltage Reconnect
High Temperature Disconnect
High-Temperature Reconnect
SKU: n/a -
FREE DELIVERYSolar WiFi Modules, Solar, Backup & UPS
Felicity Solar DTU Wireless Module; WiFi-Enabled Solar Monitoring, IoT Integration, IP65 Waterproof, Real-Time Data Tracking
-17%
Solar WiFi Modules, Solar, Backup & UPSFelicity Solar DTU Wireless Module; WiFi-Enabled Solar Monitoring, IoT Integration, IP65 Waterproof, Real-Time Data Tracking
Felicity Solar DTU Wireless Module
-
Real-Time Monitoring: You can track your solar generation, battery status, and energy consumption via the F-Solar Mobile App (Android/iOS) or web portal.
-
Smart WiFi Connectivity: Effortlessly connect your solar power system to your home WiFi network for seamless data tracking and system management.
-
IoT Integration & Analytics: Optimize energy usage, monitor performance trends, and receive instant system alerts for proactive maintenance.
-
Remote Access & Control: Adjust system settings and monitor performance from anywhere through the user-friendly mobile app or web interface.
-
IP65 Waterproof & Durable: Designed with ABS material for robust protection against dust, rain, and extreme temperatures (-20°C to 60°C).
-
Easy Plug-and-Play Installation: No technical expertise is needed. Connect to IVEM3024/5048/6048/8048/1048 inverters using the included communication cable.
-
Energy Efficiency Optimization: Analyze energy consumption patterns and adjust settings to maximize solar utilization and cost savings.
-
Instant Alerts & Proactive Maintenance: Get real-time notifications for system performance issues, ensuring timely troubleshooting.
-
User-Friendly Interface: Navigate and manage your solar system effortlessly through the intuitive mobile app, designed for both beginners and experts.
Technical Specifications:
- Brand: Felicity Solar
- Connectivity: WiFi 2.4 GHz
- Compatibility: Most home solar systems & inverters (IVEM3024/5048/6048 models)
- Waterproof Rating: IP65
- Power Supply: USB or Direct Inverter Connection
- Data Transmission Rate: Up to 300 Mbps
- Operating Temperature: -20°C to 60°C
- Certification: CE, RoHS
