Victron Phoenix 1200VA 24V Inverter VE.Direct; 1000W Continuous Power, 2200W Peak, Pure Sine Wave, ECO Mode, Remote On/Off

Original price was: UGX 1,300,000.Current price is: UGX 1,090,000.

The Victron Phoenix 24/1200 Inverter VE.Direct is a high-capacity pure sine wave inverter designed to convert 24V DC power into clean 230V AC output for use with sensitive electronics and demanding appliances. It delivers 1000W of continuous output (1200VA) and up to 2200W peak power. With VE.Direct connectivity, remote on/off capabilities, and ECO mode, it’s a robust and intelligent solution for off-grid, mobile, or backup systems.

  • Model: Victron Phoenix Inverter 24/1200 VE.Direct
  • Continuous Output Power at 25°C: 1200VA
  • Output Power at 40°C: 1000W
  • Peak Power: 2200W
  • Input Voltage Range: 18.4V – 34.0V DC
  • Output Voltage / Frequency: 230VAC ±3%, 50Hz or 60Hz ±0.1% (user configurable)
  • Max Efficiency: 91%
  • Zero-load Power Consumption: 8W (1.5W in ECO mode)
  • DC Connection: Screw terminals
  • Max Cable Cross-Section: 25 mm² / AWG 4
  • Dimensions (H x W x D): 117 x 232 x 327 mm
  • Weight: 7.4 kg
  • Cooling: Fan-assisted
  • IP Rating: IP21
  • Operating Temperature: –40°C to +65°C (derating above 40°C)
Categories , , , Brand:
Post on Faacebook
Post on X
Share via WhatsApp
Print
Send via Email

Description

Victron Phoenix 1200VA 24V Inverter VE.Direct specifications

  • Model: Victron Phoenix Inverter 24/1200 VE.Direct
  • Continuous Output Power at 25°C: 1200VA
  • Output Power at 40°C: 1000W
  • Peak Power: 2200W
  • Input Voltage Range: 18.4V – 34.0V DC
  • Output Voltage / Frequency: 230VAC ±3%, 50Hz or 60Hz ±0.1% (user configurable)
  • Max Efficiency: 91%
  • Zero-load Power Consumption: 8W (1.5W in ECO mode)
  • DC Connection: Screw terminals
  • Max Cable Cross-Section: 25 mm² / AWG 4
  • Dimensions (H x W x D): 117 x 232 x 327 mm
  • Weight: 7.4 kg
  • Cooling: Fan-assisted
  • IP Rating: IP21
  • Operating Temperature: –40°C to +65°C (derating above 40°C)

Key Features:

  • Pure Sine Wave Output: Ensures compatibility with all AC appliances, including sensitive equipment
  • VE.Direct Port: Enables configuration and real-time monitoring via USB or Bluetooth (dongle sold separately)
  • Remote On/Off Terminal: Allows control through external switches or control systems
  • ECO Mode: Minimises power draw when load is low
  • High Surge Capacity: Handles devices with high startup demand like pumps and compressors
  • Comprehensive Electronic Protections: Against overload, short circuit, battery issues, and overheating
  • LED Diagnostics: Provides quick system feedback and fault status

Ideal For:

  • Off-grid homes and solar power systems using 24V batteries
  • Backup systems for office equipment, fridges, routers, and lighting
  • Boats, campervans, mobile clinics, and utility vehicles
  • Applications requiring reliable and clean power for mixed loads
