Dyness PowerBrick Max 16kWh 51.2V Lithium Battery; LiFePO₄, 314Ah, 95% DOD, 8000+ Cycles, Built-in BMS, Optional WiFi, Scalable up to 50 Units

Dyness PowerBrick Max 16kWh 51.2V Lithium Battery

• 16kWh lithium battery capacity for reliable solar energy storage and backup power.
• 51.2V 314Ah LiFePO₄ battery configuration for low-voltage solar systems.
• 95% depth of discharge allows more usable battery energy.
• 8000+ cycle life for long-term performance and lower lifetime storage cost.
• Operating voltage range of 44.8VDC to 57.6VDC.
• Recommended 140A charge and discharge current for stable daily use.
• Maximum 200A charge and discharge current for higher-demand applications.
• Built-in fire extinguisher for enhanced battery safety.
• Built-in BMS communication for compatible inverter integration.
• Supports up to 50 units in parallel for large storage systems.

Dyness PowerBrick Max 16kWh 51.2V Lithium Battery Specifications

The Dyness PowerBrick Max 16kWh Lithium Battery is a high-capacity low-voltage solar storage battery designed for homes, businesses, institutions, and commercial backup power systems. With 51.2V 314Ah capacity, LiFePO₄ battery technology, 95% depth of discharge, and 8000+ cycle life, it provides dependable stored power for hybrid solar, off-grid, and backup applications.

The PowerBrick Max is built for flexible energy storage expansion. A single unit provides 16kWh, while four units can deliver a total capacity of 64kWh. For larger projects, the system supports up to 50 batteries in parallel. It also includes BMS communication, optional WiFi support, and a built-in fire extinguisher for improved safety and monitoring.

Battery

• Brand: Dyness
• Model: PowerBrick Max
• Battery Type: LiFePO₄ Lithium Battery
• Nominal Voltage: 51.2V
• Nominal Capacity: 314Ah
• Energy Capacity: 16kWh
• Depth of Discharge: 95%
• Cycle Life: 8000+ cycles
• Operating Voltage Range: 44.8VDC to 57.6VDC

Charge and Discharge

• Recommended Charge Current: 140A
• Recommended Discharge Current: 140A
• Maximum Charge Current: 200A
• Maximum Discharge Current: 200A
• Recommended Discharge Rate: 0.5C

Safety and Protection

• Built-in Fire Extinguisher: Yes
• Protection Level: IP20
• Battery Management System: Yes
• BMS Communication: Supported

Monitoring and Communication

• BMS Communication: Supported
• WiFi Support: Optional
• Communication Support: Compatible inverter communication through BMS

Scalability

• Maximum Parallel Connection: Up to 50 units
• Capacity with 4 Units: 64kWh
• Maximum Scalable Capacity: Up to 800kWh, based on 50 units of 16kWh each

Installation

• Installation Type: Wall-mounted or rack-mounted installation
• Suitable System Type: Low-voltage solar, hybrid, off-grid, and backup power systems

Physical Specifications

• Dimensions: 435 × 233 × 857mm
• Net Weight: Approximately 116kg

The Dyness PowerBrick Max is a low-voltage lithium battery designed for compatible 48V/51.2V hybrid and off-grid inverter systems. Before installation, compatibility should be confirmed based on the inverter’s battery voltage range, BMS communication protocol, charge/discharge current limits, and approved battery list.
