Deye 30kW 3-Phase HV Hybrid Solar Inverter SUN-30K-SG01HP3-EU-BM3; 3 MPPT, 48kW PV, 150-850V MPPT, 1000V Voc, 100A, IP65

Deye 30kW 3-Phase High Voltage Hybrid Solar Inverter

• 30kW three-phase high-voltage hybrid solar inverter
• Supports high-voltage lithium battery systems from 160V to 800V
• 3 MPPT trackers for flexible solar array design
• Up to 48kW maximum DC PV input power
• Up to 60kW maximum PV access power
• Wide 150V - 850V MPPT operating voltage range
• 1000V maximum PV open-circuit voltage
• 100A total charge/discharge capacity through dual battery input
• Supports up to 10 units in parallel for larger systems
• IP65-rated design with optional WiFi/GPRS/Bluetooth/4G/LAN monitoring

Deye 30kW 3-Phase HV Hybrid Solar Inverter SUN-30K-SG01HP3-EU-BM3

The Deye SUN-30K-SG01HP3-EU-BM3 30kW Three-Phase HV Hybrid Solar Inverter is a powerful commercial-grade solar storage inverter for large homes, offices, farms, schools, clinics, factories and business premises that need high solar input capacity, high-voltage battery support and three-phase power.

It supports 160V - 800V high-voltage lithium batteries, helping improve efficiency in larger storage systems. With 3 MPPT trackers, up to 48kW maximum DC PV input power, 60kW PV access power, 1000V maximum PV input voltage and a wide 150V - 850V MPPT range, it gives installers strong flexibility for large solar arrays.

The inverter also supports 100% unbalanced output, AC coupling, diesel generator energy storage, 6 time periods for battery charging/discharging, and up to 10 units in parallel for scalable on-grid or off-grid system designs. Deye lists this model under its three-phase high-voltage hybrid inverter range with HV battery support, 100A charge/discharge current and optional monitoring through GPRS/WiFi/Bluetooth/4G/LAN.

This is an inverter only. Batteries, solar panels and installation accessories are sold separately.

Best For

The Deye SUN-30K-SG01HP3-EU-BM3 is best for large homes, offices, farms, schools, clinics, factories, apartment blocks, commercial buildings and larger solar backup systems that need a powerful three-phase hybrid inverter with high-voltage battery support and high PV input capacity.

Inverter Output

• Brand: Deye
• Model: SUN-30K-SG01HP3-EU-BM3
• Product type: Three-phase high-voltage hybrid solar inverter
• Rated AC input/output active power: 30,000W / 30kW
• Maximum AC input/output apparent power: 33,000VA
• Peak power off-grid: 1.5 times rated power for 10 seconds
• Rated input/output voltage: 220/380V, 230/400V
• Grid connection form: 3L + N + PE
• Rated grid frequency: 50Hz / 60Hz
• Frequency range: 45-55Hz at 50Hz / 55-65Hz at 60Hz
• Power factor adjustment range: 0.8 leading to 0.8 lagging
• Total current harmonic distortion: THDi less than 3% at nominal power
• DC injection current: Less than 0.5% In

Battery & Charging

• Battery type: Lithium-ion
• Battery voltage range: 160V - 800V
• Number of battery inputs: 2
• Maximum charging current: 50A + 50A
• Maximum discharging current: 50A + 50A
• Total charge/discharge current: 100A
• Lithium battery charging strategy: Self-adaption to BMS
• High-voltage battery support: Yes
• Multiple battery parallel support: Yes

Solar Input

• Number of MPPT trackers: 3
• String configuration: 2 + 2 + 2 strings per MPPT
• Maximum PV access power: 60,000W
• Maximum DC input power: 48,000W
• Maximum DC input voltage: 1000V
• Start-up voltage: 180V
• MPPT operating voltage range: 150V - 850V
• Rated DC input voltage: 600V
• Maximum operating PV input current: 36A + 36A + 36A
• Maximum input short-circuit current: 55A + 55A + 55A
• MPPT efficiency: More than 99%

Grid, Generator & System Functions

• AC coupling: Supported
• Diesel generator energy storage: Supported
• Time-of-use battery charge/discharge: 6 time periods
• 100% unbalanced output: Supported on each phase
• Maximum continuous AC passthrough from grid to load: 200A
• Parallel operation: Up to 10 units for on-grid and off-grid operation
• Application: Three-phase solar storage, commercial backup, hybrid solar and high-voltage battery systems

Monitoring & Communication

• Communication interface: RS485 / RS232 / CAN
• Monitoring options: GPRS / WiFi / Bluetooth / 4G / LAN, optional
• BMS communication: Supported for compatible lithium batteries
• Remote monitoring: Supported with compatible monitoring accessories

Efficiency & Protection

• Maximum efficiency: 97.6%
• European efficiency: 97.0%
• Surge protection level: Type II DC / Type II AC
• Protection features: DC reverse polarity protection, AC output overcurrent protection, thermal protection, AC output overvoltage protection, AC output short-circuit protection, DC component monitoring, anti-islanding protection, DC switch, insulation impedance detection and residual current detection

General Specifications

• Protection rating: IP65
• Inverter topology: Non-isolated
• Cooling method: Intelligent air cooling
• Operating temperature range: -40°C to +60°C, derating above 45°C
• Permissible humidity: 0% - 100%
• Permissible altitude: 2000m
• Noise level: ≤65dB
• Cabinet size: 527 × 894 × 294mm, excluding connectors and brackets
• Weight: 80kg
• Warranty: 5 years / 10 years depending on final installation site and warranty policy

• This is an inverter only. Batteries and solar panels are not included.
• It requires a compatible high-voltage lithium battery system within the 160V - 800V range.
• Solar panels must be sized within the 48kW max DC input, 60kW PV access power, 1000V Voc, 36A + 36A + 36A input current and 150V - 850V MPPT range.
• This is a three-phase inverter, so the site must have a suitable three-phase electrical design.
• For lithium batteries, confirm BMS communication compatibility with the selected battery brand and model.
• Although the inverter is IP65-rated, installation should still follow correct outdoor mounting, shading, ventilation, cable gland and surge protection practices.
• Parallel systems require professional design, correct battery sizing, correct AC/DC protection and proper inverter settings.
• Use a qualified solar technician for installation, configuration, earthing, surge protection, testing and commissioning.
