Description
Victron Phoenix 375VA 24V Inverter VE.Direct specifications
Technical Specifications:
- Model: Victron Phoenix Inverter 24/375 VE.Direct
- Continuous Output Power at 25°C: 375VA
- Output Power at 40°C: 300W
- Peak Power: 700W
- Input Voltage Range: 18.4V – 34.0V DC
- Output Voltage / Frequency: 230VAC ±3%, 50Hz or 60Hz ±0.1% (user configurable)
- Max Efficiency: 89%
- Zero-load Power Consumption: 6.1W (1.4W in ECO mode)
- DC Connection: Screw terminals (no special tools needed)
- Dimensions (H x W x D): 86 x 165 x 260 mm
- Weight: 3.0 kg
- Cooling: Natural convection
- IP Rating: IP21
- Operating Temperature: –40°C to +65°C (derates above 40°C)
Key Features:
- Pure Sine Wave Output: Safe for sensitive electronics like laptops, routers, and TVs
- VE.Direct Communication Port: Allows for advanced configuration and monitoring via USB or Bluetooth dongle
- Remote On/Off Terminal: Supports external control through a switch or relay
- ECO Mode: Reduces power consumption when load is low
- High Start-up Power: Suitable for loads with high inrush current like LED drivers and small tools
- Built-in Protections: Against short circuits, overloads, battery voltage extremes, and overheating
- LED Status Indicators: Provide at-a-glance system diagnostics
Ideal For:
- Solar power systems with 24V battery banks
- Mobile setups (vans, RVs, boats)
- Off-grid homes and cabins
- Backup power for essential electronics
