Description
Victron Phoenix 1200VA 48V Inverter VE.Direct specifications
- Model: Victron Phoenix Inverter 48/1200 VE.Direct
- Continuous Output Power at 25°C: 1200VA
- Output Power at 40°C: 1000W
- Peak Power: 2200W
- Input Voltage Range: 36.8V – 62.0V DC
- Output Voltage / Frequency: 230VAC ±3%, 50Hz or 60Hz ±0.1% (adjustable)
- Max Efficiency: 92%
- Zero-load Power Consumption: 10W (1.5W in ECO mode)
- DC Connection: Screw terminals
- Max Cable Cross-Section: 25 mm² / AWG 4
- Dimensions (H x W x D): 117 x 232 x 327 mm
- Weight: 7.4 kg
- Cooling: Fan-assisted
- IP Rating: IP21
- Operating Temperature: –40°C to +65°C (derates above 40°C)
Key Features:
- Pure Sine Wave Output: Delivers stable AC power for sensitive equipment
- VE.Direct Communication Port: Supports USB/Bluetooth monitoring and full inverter configuration
- Remote On/Off Terminal: Allows integration with external control systems
- ECO Mode: Reduces energy usage under low-load conditions
- High Surge Power: Suitable for starting fridges, pumps, tools, and other inductive loads
- Comprehensive Protection: Includes overload, short circuit, over/under voltage, and over-temperature protection
- LED Indicators: Quick visual diagnostics and fault alerts
- Ideal For:
- Off-grid homes and solar power systems using 24V batteries
- Backup systems for office equipment, fridges, routers, and lighting
- Boats, campervans, mobile clinics, and utility vehicles
- Applications requiring reliable and clean power for mixed loads
Ideal For:
- Powering small AC devices off-grid
- Vehicle-based power systems (RVs, boats)
- Backup power for lights and electronics
- Remote installations requiring efficient small inverters
